煤矿水仓清理机器人全新一代煤矿井下水仓清理设备
全新一代煤矿井下水仓清理设备
暂无定价
A brushless DC motor is a synchronous electric motor which is powered by direct-current electricity (DC) and which has an electronically controlled commutation system, instead of a mechanical commutation system based on brushes. In such motors, current and torque, voltage and rpm are linearly related.
项目 | 性能 |
型号 | 42 mm |
极数 | 8 |
相数 | 3 |
额定电压 | 24 V |
额定转速 | 4000 RPM |
额定转矩 | 0.25 Nm |
峰值转矩 | 0.75 Nm |
转矩常数 | 0.036 Nm/A |
电阻 | 0.28 Ω |
电感 | 0.54 mH |
峰值电流 | 20 A |
转动惯量 | 96 g-cm² |
重量 | 0.8 Kg |
长度 | 100 mm |
